Specification
We review drawings, glazing schedules and control intent, then issue a specification and budget cost.
Switchable glazing
Switchable glazing specified and installed for commercial projects
Switchable smart glass, retrofit smart film and UV film, specified, supplied and installed across the UK for architects, main contractors and fit-out teams.
- 100ms
- Switching timeClear to private
- 87%
- Light transmissionPowered state
- 99%
- UV filteredAcross both states
- 10 W/m²
- Power drawSteady state
State
Clear
Powered · 87% light transmission
Live demonstration
Cycling automatically - press to take control.
Products
The right glazing package for your project
Process
One team from specification to handover
We hold the glass, the film and the electrical drive under a single package, so the interfaces are ours to resolve.
Survey
Site survey confirms opening sizes, frame details, cable routes and power positions before manufacture.
Manufacture
Units or film are produced to the approved schedule, with busbar positions and lead-outs set to suit the design.
Delivery
Protected delivery to programme, sequenced with the glazing or fit-out contractor as required.
Installation & commissioning
Our installers glaze or apply the film, fit the drive we supply and commission the controls. Electrical supplies and connections are carried out by others.
Handover & aftercare
O&M documentation, warranty registration and a named contact for ongoing maintenance and support.
Sectors
Project-led solutions for demanding building sectors
Questions
Questions before you specify
Further detail, including glass build-ups and control schematics, is available on request.
Switching between the clear and private states takes approximately 100 milliseconds in either direction. There is no perceptible delay in use.
Both smart glass and smart film are private in their unpowered state, so the panels default to opaque when power is removed. Where a clear fail state is required, we can specify a small UPS on the drive circuit.
Power consumption is under 0.5 W/ft² (10 W/m²), drawn only while the glass is held clear. The driving voltage is 48–60 VAC ±5 V, and a dedicated supply is sized at approximately 6 W/m².
Yes. Retrofit smart film is applied to the inner face of existing glass in situ. It suits occupied buildings where replacing the glazing would be disruptive or uneconomic.
A remote control is included. A manual wall switch, motion sensor, app control and voice control are all available as options, confirmed for your project at specification stage.
Electronics and accessories carry one year, retrofit smart film two years, and laminated glass and sealed glass units five years. Life expectancy is more than ten years, depending on operating conditions, installation quality, switching frequency and maintenance.
Next step
Submit your drawings for specification and budget costing.
Glazing schedules, elevations or a simple room list are enough to begin. Budget costs are typically issued within two working days.
